안녕하세요 kubelet 실행시 cgroup driver가 cgroupfs로 나옵니다
14일 전
failed to run Kubelet: misconfiguration: kubelet cgroup driver: "cgroupfs" is different from docker cgroup driver: "systemd"
공식문서에는 이 위치에 파일을 찾으라해서 찾았는데
/etc/systemd/system/kubelet.service 위치에 없어서 찾다보니
vi /etc/systemd/system/kubelet.service.d/10-kubeadm.conf 에
Environment="KUBELET_CGROUP_ARGS=--cgroup-driver=systemd“ 추가 했는데도
kubelet cgroup driver가 cgroupfs로 되는 문제가 있는데 어떻게 해야되나요?
kubelet log 입니다
kubelet 실행시 로그입니다
I0629 10:26:20.043880 1157 server.go:417] Version: v1.18.4
I0629 10:26:20.044141 1157 plugins.go:100] No cloud provider specified.
W0629 10:26:20.044171 1157 server.go:560] standalone mode, no API client
W0629 10:26:20.052017 1157 container_manager_linux.go:912] CPUAccounting not enabled for pid: 1157
W0629 10:26:20.052031 1157 container_manager_linux.go:915] MemoryAccounting not enabled for pid: 1157
W0629 10:26:20.144960 1157 server.go:474] No api server defined - no events will be sent to API server.
I0629 10:26:20.144996 1157 server.go:647] --cgroups-per-qos enabled, but --cgroup-root was not specified. defaulting to /
I0629 10:26:20.145378 1157 container_manager_linux.go:266] container manager verified user specified cgroup-root exists: []
I0629 10:26:20.145394 1157 container_manager_linux.go:271] Creating Container Manager object based on Node Config: {RuntimeCgroupsName: SystemCgroupsName: KubeletCgroupsName: ContainerRuntime:docker CgroupsPerQOS:true CgroupRoot:/ CgroupDriver:cgroupfs KubeletRootDir:/var/lib/kubelet ProtectKernelDefaults:false NodeAllocatableConfig:{KubeReservedCgroupName: SystemReservedCgroupName: ReservedSystemCPUs: EnforceNodeAllocatable:map[pods:{}] KubeReserved:map[] SystemReserved:map[] HardEvictionThresholds:[{Signal:memory.available Operator:LessThan Value:{Quantity:100Mi Percentage:0} GracePeriod:0s MinReclaim:<nil>} {Signal:nodefs.available Operator:LessThan Value:{Quantity:<nil> Percentage:0.1} GracePeriod:0s MinReclaim:<nil>} {Signal:nodefs.inodesFree Operator:LessThan Value:{Quantity:<nil> Percentage:0.05} GracePeriod:0s MinReclaim:<nil>} {Signal:imagefs.available Operator:LessThan Value:{Quantity:<nil> Percentage:0.15} GracePeriod:0s MinReclaim:<nil>}]} QOSReserved:map[] ExperimentalCPUManagerPolicy:none ExperimentalCPUManagerReconcilePeriod:10s ExperimentalPodPidsLimit:-1 EnforceCPULimits:true CPUCFSQuotaPeriod:100ms ExperimentalTopologyManagerPolicy:none}
I0629 10:26:20.145511 1157 topology_manager.go:126] [topologymanager] Creating topology manager with none policy
I0629 10:26:20.145520 1157 container_manager_linux.go:301] [topologymanager] Initializing Topology Manager with none policy
I0629 10:26:20.145526 1157 container_manager_linux.go:306] Creating device plugin manager: true
I0629 10:26:20.145904 1157 client.go:75] Connecting to docker on unix:///var/run/docker.sock
I0629 10:26:20.145924 1157 client.go:92] Start docker client with request timeout=2m0s
W0629 10:26:20.153507 1157 docker_service.go:561] Hairpin mode set to "promiscuous-bridge" but kubenet is not enabled, falling back to "hairpin-veth"
I0629 10:26:20.153534 1157 docker_service.go:238] Hairpin mode set to "hairpin-veth"
W0629 10:26:20.153647 1157 cni.go:237] Unable to update cni config: no networks found in /etc/cni/net.d
I0629 10:26:20.159266 1157 docker_service.go:253] Docker cri networking managed by kubernetes.io/no-op
I0629 10:26:20.174650 1157 docker_service.go:258] Docker Info: &{ID:T2I3:EWJ7:VEJY:RXBX:DVXY:MVVL:GZNX:YXOU:PIPL:QAEP:EEHU:VNPV Containers:47 ContainersRunning:16 ContainersPaused:0 ContainersStopped:31 Images:56 Driver:overlay2 DriverStatus:[[Backing Filesystem xfs] [Supports d_type true] [Native Overlay Diff true]] SystemStatus:[] Plugins:{Volume:[local] Network:[bridge host ipvlan macvlan null overlay] Authorization:[] Log:[awslogs fluentd gcplogs gelf journald json-file local logentries splunk syslog]} MemoryLimit:true SwapLimit:true KernelMemory:true KernelMemoryTCP:true CPUCfsPeriod:true CPUCfsQuota:true CPUShares:true CPUSet:true PidsLimit:true IPv4Forwarding:true BridgeNfIptables:true BridgeNfIP6tables:true Debug:false NFd:109 OomKillDisable:true NGoroutines:104 SystemTime:2020-06-29T10:26:20.161085127+09:00 LoggingDriver:json-file CgroupDriver:systemd NEventsListener:0 KernelVersion:3.10.0-1062.18.1.el7.x86_64 OperatingSystem:CentOS Linux 7 (Core) OSType:linux Architecture:x86_64 IndexServerAddress:https://index.docker.io/v1/ RegistryConfig:0xc0002d05b0 NCPU:4 MemTotal:8168255488 GenericResources:[] DockerRootDir:/var/lib/docker HTTPProxy: HTTPSProxy: NoProxy: Name:k8shost Labels:[] ExperimentalBuild:false ServerVersion:19.03.12 ClusterStore: ClusterAdvertise: Runtimes:map[runc:{Path:runc Args:[]}] DefaultRuntime:runc Swarm:{NodeID: NodeAddr: LocalNodeState:inactive ControlAvailable:false Error: RemoteManagers:[] Nodes:0 Managers:0 Cluster:<nil> Warnings:[]} LiveRestoreEnabled:false Isolation: InitBinary:docker-init ContainerdCommit:{ID:7ad184331fa3e55e52b890ea95e65ba581ae3429 Expected:7ad184331fa3e55e52b890ea95e65ba581ae3429} RuncCommit:{ID:dc9208a3303feef5b3839f4323d9beb36df0a9dd Expected:dc9208a3303feef5b3839f4323d9beb36df0a9dd} InitCommit:{ID:fec3683 Expected:fec3683} SecurityOptions:[name=seccomp,profile=default] ProductLicense: Warnings:[]}
F0629 10:26:20.174747 1157 server.go:274] failed to run Kubelet: misconfiguration: kubelet cgroup driver: "cgroupfs" is different from docker cgroup driver: "systemd"
